Supplied in primer for site painting. Maximum Deliverable Length 10...
£309.00 – £3,193.00Price range: £309.00 through £3,193.00 ex VAT (£370.80 – £3,831.60 inc VAT)
Established 1893 | BS 460:2002 Certified | UK & International Supply | Expert Technical Support | 0333 987 4452
£309.00 – £3,193.00Price range: £309.00 through £3,193.00 ex VAT (£370.80 – £3,831.60 inc VAT)
£420.00 – £4,060.00Price range: £420.00 through £4,060.00 ex VAT (£504.00 – £4,872.00 inc VAT)
£190.00 – £235.00Price range: £190.00 through £235.00 ex VAT (£228.00 – £282.00 inc VAT)
| Single Section- Output/Dimensions | ||
| Height | mm | 950 |
| ins | 37.40 | |
| Centres | mm | 782 |
| ins | 30.78 | |
| Section Width | mm | 78 |
| ins | 3.07 | |
| Depth | mm | 250 |
| ins | 9.84 | |
| Water Volume per Section | lit | 2.8 |
| gal | 0.62 | |
| Dry Weight per Section | kg | 14.4 |
| lbs | 31.68 | |
| Heat Output per Section | watts | 231.2 |
| Btu/hr | 788 | |
| Heat Output per Section | watts | 182.4 |
| En 442 75-65-20°C | Btu/hr | 623 |
| Thermal Output | |||
| °C | Factor | °C | Factor |
| 5 | 0.046 | 45 | 0.700 |
| 10 | 0.108 | 50 | 0.798 |
| 15 | 0.179 | 55 | 0.898 |
| 20 | 0.256 | 60 | 1.000 |
| 25 | 0.338 | 65 | 1.104 |
| 30 | 0.423 | 70 | 1.211 |
| 35 | 0.512 | 75 | 1.319 |
| 40 | 0.605 | ||
| Multiple Section – Output /Watts 90/70/20°C | ||
| Sections | L – Length mm | Output 950 High |
| 3 Section | 234 | 694 |
| 4 Section | 312 | 925 |
| 5 Section | 390 | 1156 |
| 6 Section | 468 | 1387 |
| 7 Section | 546 | 1618 |
| 8 Section | 624 | 1850 |
| 9 Section | 702 | 2080 |
| 10 Section | 780 | 2312 |
| 11 Section | 858 | 2543 |
| 12 Section | 936 | 2775 |
| 13 Section | 1014 | 3006 |
| 14 Section | 1092 | 3237 |
| 15 Section | 1170 | 3468 |
| Further lengths are possible by joining sections. | ||
